Compact and Lightweight
Digital CD Ignition System
High Grade Marine Alloy Construction
Stainless Steel Water Pump Housing
Zinc Coated Water Passages
Rated for Saltwater Use
Sacrificial Zinc Anodes
Forward-Neutral Gear Shift
360° Steering w/ Tension Feature
Twist-Grip Throttle with Tension Control
Integrated Carry Handle
Thermostat Controlled Water Cooling
Visual Oil Level Indicator
Over-Rev Protection
4 Trim Level Positions
Below-The-Water Exhaust
1.0 Liter (.30 Gallon) Integral Fuel Tank
Safety Lanyard Stop Switch
Owner's Manual
Mercury Marine 3-Year Warranty

specifications
MODEL 1F02201LK
MODEL YEAR 2025
SKU 2.5MH-25
WEIGHT 41.0 lb
MANUFACTURER Mercury
COUNTRY OF MANUFACTURE Japan
HORSEPOWER 2.5hp
SHAFT LENGTH 15" (Short)
STEERING Tiller
STARTING Manual
TRIM & TILT Manual
FUEL DELIVERY Carburetor
FUEL TANK Internal
CYLINDER(S) 1
DISPLACEMENT 85 cc
BORE AND STROKE 55 x 36 mm
FULL THROTTLE RPM RANGE 5000-6000
IGNITION SYSTEM Digital CD Ignition w/Electronic Spark Advance
INDUCTION SCAVENGING OHV
VALVES PER CYLINDER 2
FUEL TYPE 87 Octane (up to 10% ethanol content)
FUEL TANK / FUEL LINE 0.3 US Gallon (0.95 liter)
OIL TYPE SAE 10W-30 (Mercury 4-Stroke Outboard Oil)
OIL CAPACITY 10 fl. Oz. (300 ml)
LUBRICATION Slinger Splashing System
ALTERNATOR Not available on 2.5hp models (4hp & up only)
COOLING SYSTEM Water-Cooled, Thermostatically Controlled
SALTWATER RATED Yes
GEAR RATIO 2.15:1
GEAR SHIFT Forward-Neutral w/ 360° Steering for Reverse
PROPELLER 7.4" Diameter x 7.0" Pitch 3-Blade Composite
In the Box

Integral Fuel Tank (0.3 gal)
Owner's Manual
Mercury 3-Year Warranty
Propeller (Composite)
Mercury 4-Stroke Oil
Tool Kit
